 QFT4-15 BLOCK MAKING  MACHINE



1.    QT4-15 can product many kinds of Solid block, Hollow block, Pavers and so on
2.    Unique material feeder system can guarantee the maximum uniformity of the material feeding
3.    This machine adopts hydraulic transmission, smooth and reliable operation, the hydraulic pressure combined with efficient vibration molding, block density, good quality

QFT4-15 PRODUCTION CAPACITY
SPEC. Block
390*190*190
 Block
390*100*190
Rectangular 200*100*60    I Shape 200*165*60 S Paver
225*112.5*60
Porous Brick
240*115*90
   SolidBrick
240*115*53
Code
Pcs/Pallet 4 8 14 8 12 12 24
Pcs/Hour 720 1440 2520 1440 2160 2160 4320
Pcs/8 Hour 5760 11520 20160 11520 17280 17280 34560
Year(300day) 24338m³ 25600m³ 120960m² 114059m² 131241m² 5180000Pcs 10370000Pcs




QFT4-15 TECHNICAL DATA
Overall Dimensions 4850*4650*2250(mm)
Pallet Size(mm) 850*550*25(Bamboo)
Machine Weight 4000kg
The Frequency Of Vibrate 50-90Hz
Max Excitation Force 50KN
Cycle Time(s) 15-20S
Installed Capacity(kw) 21KW
